Automatic Chicken Coop Door Drive Mechanisms

A major considerations when selecting an automatic chicken coop door is the mechanical process used to open and close your coop door.

There are many ingenious designs ranging in methods including cables and pulleys, gears and Rube Goldberg automatic chicken coop doors like this one:

 Rube Goldberg Automatic Chicken Coop Door

Although these methods may work, challenges tend to surface using these methods which may compromise the safety of your hens.

We designed our automatic chicken door to keep it simple, yet effective.  A high-torque gear motor is connected directly to a 5/8 inch Acme Worm Drive



The worm drive is attached directly to the door.

This design provides a simple, yet effective means by which to open and close the door as well as keeping predators out.  The simple design also makes it virtually maintenance free.

Our coop door worm drives are custom manufactured locally in western Pennsylvania by Baden Steelbar and Bolt Corp. (http://www.badensteel.com). They’ve been in business for over 50 years and provide us with custom cut, drilled and finished worm drives.  They start with 14 foot rods of 5/8 inch Acme threaded rod and cut it down to our size specifications.  Holes are precisely drilled into the threaded rod providing a solid connection to the drive motor.

The drive motor is just as important.  We offer two permanent magnet gear motor options in our chicken coop doors:

Standard Gear Motor: High-torque motor turns the worm drive about 30 times per minute.  This provides a door open and close time of about 3 minutes.

High-Speed Gear Motor: High-torque motor turns the worm drive about 90 times per minute.  This provides a door open and close time of a little less than 1 minute.

Both of our motor drive options consume very little power when operating and are ideal solutions for our solar powered automatic chicken coop door.

When choosing an automatic chicken coop door it is important to consider the long-term viability of the solution.

A general "rule of thumb" used in many manufacturing and consumer product scenarios:

More Moving Parts = More Chance of Failure





Coop Tender Automatic Chicken Coop Door = 1 Moving Part

Coop Tender Automatic Chicken Coop Door has one moving part.  It works on the same principle as a linear actuator.

coop door linear actuator worm drive example

The worm drive is the only moving part in our automatic chicken coop door.  We believe that this type of design is imperative to long-term dependability.

When comparing automatic chicken coop doors, consider the long term viability of the mechanical design.
